MAX5907EEE+T
RoHS
RoHS compliant
RoHS compliantPackage 16-SSOP (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Hot Swap Controllers
Description
Matte Tin (Sn) EAR99 MAX5907 Circuit Breaker Current Limit Fault Timeout hot swap controller 4.89mm 1.2mA 1V~13.2V -40C~85C
PDF
/
Inventory: 9568
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 4.89mm
Height Seated (Max) 1.73mm
Technical
Feature Pins INC+, LIM1, LIM2, MON1, MON2, ON, OUTC, PGOOD, TIM
Programmable Features Circuit Breaker, Current Limit, Fault Timeout
Internal Switch(s) No
Current - Supply 1.2mA
Adjustable Threshold YES
Number of Channels 2
Supply Voltage-Min (Vsup) 1V
JESD-30 Code R-PDSO-G16
Pin Count 16
Base Part Number MAX5907
Terminal Pitch 0.635mm
Supply Voltage 3.3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 1V~13.2V
Technology BICMOS
Subcategory Power Management Circuits
Applications PCI Express?
Terminal Finish Matte Tin (Sn)
Type Hot Swap Controller, Sequencer
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Latched Fault, UVLO
JESD-609 Code e3
Series VariableSpeed/BiLevel?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 16-SSOP (0.154, 3.90mm Width)
Mounting Type Surface Mount
