MAX5902LCETT+T
RoHS
RoHS compliant
RoHS compliantPackage 6-WDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Hot Swap Controllers
Description
Obsolete Surface Mount BICMOS ROHS3Compliant Hot Swap Controller -40C~85C 9V~72V 1mA 3mm
PDF
/
Buying Options
Total Price: USD $3.23
Unit Price: USD $3.22715
≥1 USD $3.22715
≥10 USD $2.64765
≥100 USD $2.565
≥500 USD $2.48235
≥1000 USD $2.3997
Inventory: 2401
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3mm
Length 3mm
Height Seated (Max) 0.8mm
Technical
Feature Pins DRAIN, (ON, /OFF), /PGOOD
Programmable Features UVLO
Internal Switch(s) No
Supply Current-Max (Isup) 2mA
Current - Supply 1mA
Adjustable Threshold NO
Number of Channels 1
Supply Voltage-Min (Vsup) 9V
Power Supplies 9/72V
Supply Voltage-Max (Vsup) 72V
Pin Count 6
Base Part Number MAX5902
Terminal Pitch 0.95mm
Supply Voltage 48V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 9V~72V
Technology BICMOS
Subcategory Power Management Circuits
Additional Feature ADJUSTABLE UNDERVOLTAGE LOCKOUT
Applications General Purpose
Terminal Finish Matte Tin (Sn)
Type Hot Swap Controller
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Fault Timeout, Latched Fault, Thermal Limit
JESD-609 Code e3
Series Simple Swapper?
Published 2007
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 6
Package / Case 6-WDFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
