LTC4260IGN#TRPBF
RoHS
RoHS compliant
RoHS compliantPackage 24-SSOP (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Hot Swap Controllers
Description
Matte Tin (Sn) EAR99 LTC4260 Auto Retry Current Limit Fault Timeout Latched Fault OVP Slew Rate UVLO hot swap controller 8.649mm 2mA 8.5V~80V -40C~85C
PDF
/
Buying Options
Total Price: USD $10.33
Unit Price: USD $10.329
≥1 USD $10.329
Inventory: 1135
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.899mm
Length 8.649mm
Technical
Feature Pins ADIN, /ALERT, /BD_PRST, FB, GPIO, INTVCC, ON, OV, SOURCE, TIMER, UV
Programmable Features Auto Retry, Current Limit, Fault Timeout, Latched Fault, OVP, Slew Rate, UVLO
Internal Switch(s) No
Supply Current-Max (Isup) 5mA
Current - Supply 2mA
Adjustable Threshold NO
Number of Channels 1
Supply Voltage-Min (Vsup) 8.5V
Power Supplies 48V
Supply Voltage-Max (Vsup) 80V
JESD-30 Code R-PDSO-G24
Pin Count 24
Base Part Number LTC4260
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.635mm
Supply Voltage 48V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 8.5V~80V
Technology CMOS
Subcategory Power Management Circuits
Applications General Purpose
Terminal Finish Matte Tin (Sn)
Type Hot Swap Controller, Monitor
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature I2C
JESD-609 Code e3
Published 2012
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 24-SSOP (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
