IPS511S
RoHS
/
Package TO-263-5
Category Integrated Circuits (ICs) / PMIC - Hot Swap Controllers
Description
Contains Lead MOS GULL WING RoHS Compliant (Type) 1.56W 150C 35V 130mOhm
PDF
/
Inventory: 8879
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Height Seated (Max) 4.8mm
Technical
Output Current Flow Direction SOURCE
Built-in Protections OVER CURRENT; THERMAL
Drain to Source Resistance 130mOhm
Output Peak Current Limit-Nom 3A
Fault Protection Over Temperature
Driver Number of Bits 1
Output Current per Channel 1.7A
Current - Output 3A
Power Dissipation 1.56W
Output Configuration High Side
Nominal Supply Current 700μA
Power Dissipation-Max 1.56W
Interface On/Off
Number of Channels 1
Operating Supply Voltage 35V
Max Output Current 1.7A
JESD-30 Code R-PSSO-G4
Pin Count 4
Time@Peak Reflow Temperature-Max (s) 30
Current Rating 5A
Supply Voltage 14V
Number of Functions 1
Peak Reflow Temperature (Cel) 225
Terminal Form GULL WING
Terminal Position SINGLE
Technology MOS
Subcategory Peripheral Drivers
Min Operating Temperature -40°C
Max Operating Temperature 150°C
Terminal Finish Tin/Lead (Sn/Pb)
Resistance 110mOhm
ECCN Code EAR99
Number of Terminations 4
Moisture Sensitivity Level (MSL) 1
Pbfree Code no
JESD-609 Code e0
Published 2000
Packaging Bulk
Physical
Number of Pins 5
Package / Case TO-263-5
Mount Surface Mount
