TLE7238SL
RoHS
/
Package SSOP
Category Integrated Circuits (ICs) / PMIC - Hot Swap Controllers
Description
Matte Tin (Sn) EAR99 SPI Serial TRANSIENT; OVER CURRENT; THERMAL; UNDER VOLTAGE hot swap controller 1.75mm 260mA 52V 150C
PDF
/
Buying Options
Total Price: USD $2.28
Unit Price: USD $2.28
≥1 USD $2.28
≥10 USD $1.87055
≥100 USD $1.8126
≥500 USD $1.7537
≥1000 USD $1.69575
Inventory: 1180
Minimum: 1
-
+
Technical Details
Technical
JESD-609 Code e3
Pbfree Code yes
Moisture Sensitivity Level (MSL) 3
Number of Terminations 24
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Max Operating Temperature 150°C
Min Operating Temperature -40°C
Subcategory Peripheral Drivers
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 0.65mm
Pin Count 24
Max Output Current 260mA
Power Supplies 3.3/5V
Supply Voltage-Min (Vsup) 3V
Number of Channels 8
Interface SPI, Serial
Nominal Supply Current 15mA
Quiescent Current 10A
Halogen Free Halogen Free
Drain to Source Voltage (Vdss) 52V
Max Dual Supply Voltage 52V
Driver Number of Bits 8
Fault Protection Over Temperature
Screening Level AEC-Q100
Turn On Time 100 μs
Output Peak Current Limit-Nom 0.38A
Supply Voltage1-Nom 13.5V
Turn Off Time 100 μs
Packaging Tape & Reel
Built-in Protections TRANSIENT; OVER CURRENT; THERMAL; UNDER VOLTAGE
Output Current Flow Direction SOURCE SINK
Supply Voltage1-Min 5.5V
Physical
Number of Pins 24
Package / Case SSOP
Mount Surface Mount
Dimensions
Height Seated (Max) 1.75mm
Width 3.9mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
