UCC27425DR
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Tape & Reel (TR) UCC27425 Low-Side ACTIVE (Last Updated: 5days ago) gate driver 40ns -40C~125C TA 4A 4A 650mW
PDF
/
Buying Options
Total Price: USD $0.9
Unit Price: USD $0.90065
≥1 USD $0.90065
≥10 USD $0.84967
≥100 USD $0.80158
≥500 USD $0.7562
≥1000 USD $0.7134
≥3000 USD $0.67302
Inventory: 4483
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 1.58mm
Width 3.91mm
Length 4.9mm
Height 1.75mm
Technical
Turn Off Time 0.05 μs
Logic Voltage - VIL, VIH 1V 2V
High Side Driver NO
Current - Peak Output (Source, Sink) 4A 4A
Gate Type N-Channel, P-Channel MOSFET
Driven Configuration Low-Side
Output Peak Current Limit-Nom 4A
Turn On Time 0.04 μs
Channel Type Independent
Interface IC Type BUFFER OR INVERTER BASED MOSFET DRIVER
Rise / Fall Time (Typ) 20ns, 15ns
Output Polarity TRUE AND INVERTED
Fall Time (Typ) 40 ns
Rise Time 40 ns
Output Characteristics TOTEM-POLE
Turn On Delay Time 150 ns
Input Type Inverting, Non-Inverting
Propagation Delay 150 ns
Max Supply Current 1.6mA
Output Current 4A
Power Dissipation 650mW
Nominal Supply Current 1.6mA
Power Supplies 4.5/15V
Max Output Current 4A
Number of Outputs 2
Pin Count 8
Base Part Number UCC27425
Supply Voltage 14V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4V~15V
Technology BICMOS
Max Power Dissipation 650mW
Subcategory MOSFET Drivers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TA
Physical
Weight 72.603129mg
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 6 Weeks
