UCC27282DRCR
RoHS
RoHS compliant
RoHS compliantPackage 10-VFDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
NO LEAD ROHS3Compliant Active Nickel/Palladium/Gold (Ni/Pd/Au) IC Gate Driver 3mm 0.9V 2.4V 2.5A 3.5A -40C~125C
PDF
/
Buying Options
Total Price: USD $1.41
Unit Price: USD $1.408
≥1 USD $1.408
≥10 USD $1.26104
≥100 USD $1.197152
≥500 USD $0.983312
≥1000 USD $0.919142
≥3000 USD $0.812275
Inventory: 1098
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3mm
Length 3mm
Height Seated (Max) 1mm
Technical
High Side Voltage - Max (Bootstrap) 120V
Turn Off Time 0.03 μs
Logic Voltage - VIL, VIH 0.9V 2.4V
High Side Driver YES
Current - Peak Output (Source, Sink) 2.5A 3.5A
Gate Type N-Channel MOSFET
Driven Configuration Half-Bridge
Supply Voltage1-Nom 12V
Turn On Time 0.03 μs
Number of Drivers 2
Channel Type Independent
Rise / Fall Time (Typ) 12ns 10ns
Output Current-Max 3.5A
Input Type Non-Inverting
JESD-30 Code S-PDSO-N10
Base Part Number UCC27282
Terminal Pitch 0.5mm
Supply Voltage 12V
Number of Functions 1
Terminal Form NO LEAD
Terminal Position DUAL
Voltage - Supply 5.5V~16V
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 10
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C
Physical
Surface Mount YES
Package / Case 10-VFDFN Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
