UCC27201DG4
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Rail/Tube UNDER VOLTAGE HALF BRIDGE BASED PERIPHERAL DRIVER DUAL gate driver 8ns 140C 3A 1.3W
PDF
/
Buying Options
Total Price: USD $0.75
Unit Price: USD $0.7524
≥1 USD $0.7524
≥10 USD $0.6175
≥100 USD $0.59755
≥500 USD $0.57855
≥1000 USD $0.55955
Inventory: 147835
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 3.91mm
Length 4.9mm
Height 1.58mm
Technical
Output Current Flow Direction SOURCE SINK
Built-in Protections UNDER VOLTAGE
Output Peak Current Limit-Nom 3A
Driver Number of Bits 2
Interface IC Type HALF BRIDGE BASED PERIPHERAL DRIVER
Output Polarity TRUE
Turn-Off Delay Time 1 ns
Fall Time (Typ) 7 ns
Rise Time 8ns
Turn On Delay Time 1 ns
Propagation Delay 20 ns
Current - Output 3A
Max Supply Current 5.5mA
Power Dissipation 1.3W
Nominal Supply Current 5.5mA
Power Dissipation-Max 1.3W
Min Supply Voltage 8V
Max Supply Voltage 17V
Temperature Grade AUTOMOTIVE
Operating Supply Voltage 12V
Max Output Current 3A
Number of Outputs 2
Pin Count 8
Frequency 1MHz
Supply Voltage 12V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Subcategory MOSFET Drivers
Min Operating Temperature -40°C
Max Operating Temperature 140°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1
JESD-609 Code e4
Packaging Rail/Tube
Physical
Weight 72.603129mg
Number of Pins 8
Package / Case SOIC
Mount Surface Mount
