UCC21222D
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Tube UCC21222 Half-Bridge TRANSIENT; UNDER VOLTAGE gate driver 5ns 6ns -40C~125C TA 4A 6A 1.25V 1.6V
PDF
/
Buying Options
Total Price: USD $4.17
Unit Price: USD $4.1712
≥1 USD $4.1712
≥10 USD $3.74616
≥100 USD $3.54156
≥500 USD $3.06944
≥1000 USD $2.912017
≥3000 USD $2.61294
Inventory: 1987
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 9.9mm
Height Seated (Max) 1.75mm
Technical
Output Current Flow Direction SOURCE SINK
Built-in Protections TRANSIENT; UNDER VOLTAGE
Logic Voltage - VIL, VIH 1.25V 1.6V
Current - Peak Output (Source, Sink) 4A 6A
Gate Type IGBT, N-Channel MOSFET
Driven Configuration Half-Bridge
Supply Voltage1-Nom 12V
Number of Drivers 2
Channel Type Independent
Interface IC Type BUFFER OR INVERTER BASED PERIPHERAL DRIVER
Rise / Fall Time (Typ) 5ns 6ns
Output Current-Max 6A
Input Type CMOS/TTL
JESD-30 Code R-PDSO-G16
Base Part Number UCC21222
Supply Voltage 3.3V
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~5.5V
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 16
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tube
Operating Temperature -40°C~125°C TA
Physical
Surface Mount YES
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
