UC3706NG4
RoHS
RoHS compliant
RoHS compliantPackage 16-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
ROHS3Compliant TRUE AND INVERTED Active TOTEM-POLE IC Gate Driver 19.3mm 0.8V 2.2V 2W 1.5A 1.5A
PDF
/
Buying Options
Total Price: USD $4.46
Unit Price: USD $4.459291
≥1 USD $4.459291
≥10 USD $4.206887
≥100 USD $3.968761
≥500 USD $3.744106
≥1000 USD $3.532174
Inventory: 1388
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 16-DIP (0.300, 7.62mm)
Number of Pins 16
Weight 1.053808g
Technical
Operating Temperature 0°C~70°C TA
Packaging Tube
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory MOSFET Drivers
Max Power Dissipation 2W
Technology BIPOLAR
Voltage - Supply 5V~40V
Terminal Position DUAL
Number of Functions 2
Supply Voltage 20V
Base Part Number UC3706
Pin Count 16
Max Output Current 1.5A
Nominal Supply Current 10mA
Power Dissipation 2W
Output Current 1.5A
Max Supply Current 10mA
Input Type Inverting, Non-Inverting
Output Characteristics TOTEM-POLE
Rise Time 140ns
Fall Time (Typ) 130 ns
Output Polarity TRUE AND INVERTED
Input Characteristics STANDARD
Rise / Fall Time (Typ) 40ns 30ns
Interface IC Type PUSH-PULL BASED MOSFET DRIVER
Channel Type Independent
Number of Drivers 2
Turn On Time 0.14 μs
Output Peak Current Limit-Nom 1.5A
Driven Configuration Low-Side
Gate Type N-Channel MOSFET
Current - Peak Output (Source, Sink) 1.5A 1.5A
High Side Driver NO
Logic Voltage - VIL, VIH 0.8V 2.2V
Turn Off Time 0.13 μs
Dimensions
Height 5.08mm
Length 19.3mm
Width 6.35mm
Thickness 3.9mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
