UC3705DG4
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Rail/Tube BUFFER OR INVERTER BASED MOSFET DRIVER DUAL BIPOLAR gate driver 90ns 70C 1.5A 40V
PDF
/
Buying Options
Total Price: USD $4.13
Unit Price: USD $4.133964
≥1 USD $4.133964
≥10 USD $3.89996
≥100 USD $3.679211
≥500 USD $3.470952
≥1000 USD $3.274478
Inventory: 1178
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 3.91mm
Length 4.9mm
Height 1.58mm
Technical
Turn Off Time 0.06 μs
High Side Driver NO
Output Peak Current Limit-Nom 1.5A
Turn On Time 0.06 μs
Number of Drivers 1
Interface IC Type BUFFER OR INVERTER BASED MOSFET DRIVER
Fall Time (Typ) 60 ns
Rise Time 90ns
Current - Output 1.5A
Element Configuration Single
Min Supply Voltage 5V
Max Supply Voltage 40V
Temperature Grade COMMERCIAL
Max Output Current 1.5A
Pin Count 8
Supply Voltage 20V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology BIPOLAR
Subcategory MOSFET Drivers
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 2
Pbfree Code yes
JESD-609 Code e4
Packaging Rail/Tube
Physical
Weight 72.603129mg
Number of Pins 8
Package / Case SOIC
Mount Surface Mount
