UC3705D
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Tube UC3705 Low-Side ACTIVE (Last Updated: 2days ago) gate driver 90ns 0C~70C TA 1.5A 1.5A 0.8V 2.2V
PDF
/
Buying Options
Total Price: USD $8.98
Unit Price: USD $8.976
≥1 USD $8.976
≥10 USD $8.11184
≥100 USD $7.73461
≥500 USD $6.71587
≥1000 USD $6.41403
≥3000 USD $5.848075
Inventory: 70
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Thickness 1.58mm
Width 3.91mm
Length 4.9mm
Height 1.75mm
Technical
Turn Off Time 0.06 μs
Logic Voltage - VIL, VIH 0.8V 2.2V
High Side Driver NO
Current - Peak Output (Source, Sink) 1.5A 1.5A
Gate Type N-Channel MOSFET
Driven Configuration Low-Side
Output Peak Current Limit-Nom 1.5A
Turn On Time 0.06 μs
Channel Type Single
Interface IC Type BUFFER OR INVERTER BASED MOSFET DRIVER
Rise / Fall Time (Typ) 60ns, 60ns
Input Characteristics STANDARD
Output Polarity TRUE AND INVERTED
Fall Time (Typ) 60 ns
Rise Time 90 ns
Output Characteristics TOTEM-POLE
Turn On Delay Time 100 ns
Input Type Inverting, Non-Inverting
Propagation Delay 100 ns
Output Current 1.5A
Nominal Supply Current 12mA
Operating Supply Voltage 20V
Max Output Current 1.5A
Number of Outputs 1
Base Part Number UC3705
Supply Voltage 20V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 5V~40V
Technology BIPOLAR
Subcategory MOSFET Drivers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tube
Operating Temperature 0°C~70°C TA
Physical
Weight 72.603129mg
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 6 Weeks
Alternative Model
