TPS2811DG4
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Rail/Tube SCHMITT TRIGGER NAND GATE BASED MOSFET DRIVER DUAL gate driver 35ns 125C 2A 730mW
PDF
/
Buying Options
Total Price: USD $1.17
Unit Price: USD $1.169119
≥1 USD $1.169119
≥10 USD $1.102944
≥100 USD $1.040511
≥500 USD $0.981613
≥1000 USD $0.926038
Inventory: 1324
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Package / Case SOIC
Number of Pins 8
Weight 75.891673mg
Technical
Packaging Rail/Tube
JESD-609 Code e4
Moisture Sensitivity Level (MSL) 1
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Max Operating Temperature 125°C
Min Operating Temperature -40°C
Subcategory MOSFET Drivers
Technology BIMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Supply Voltage 10V
Pin Count 8
Number of Outputs 2
Max Output Current 2mA
Power Supplies 10V
Temperature Grade AUTOMOTIVE
Max Supply Voltage 14V
Min Supply Voltage 4V
Power Dissipation-Max 730mW
Nominal Supply Current 200nA
Power Dissipation 730mW
Current - Output 2A
Propagation Delay 50 ns
Turn On Delay Time 50 ns
Output Characteristics TOTEM-POLE
Rise Time 35ns
Fall Time (Typ) 35 ns
Output Polarity INVERTED
Input Characteristics SCHMITT TRIGGER
Interface IC Type NAND GATE BASED MOSFET DRIVER
Turn On Time 0.05 μs
Output Peak Current Limit-Nom 2A
High Side Driver YES
Turn Off Time 0.05 μs
Dimensions
Height Seated (Max) 1.75mm
Length 4.9mm
Width 3.9mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
