TPIC44L01DB
RoHS
RoHS compliant
RoHS compliantPackage 24-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
GULL WING ROHS3Compliant Obsolete Nickel/Palladium/Gold (Ni/Pd/Au) IC Gate Driver 8.2mm 5V 1.2mA 1.2mA -40C~150C TJ
PDF
/
Buying Options
Total Price: USD $1.38
Unit Price: USD $1.3832
≥1 USD $1.3832
≥10 USD $1.13525
≥100 USD $1.09915
≥500 USD $1.064
≥1000 USD $1.02885
Inventory: 2745
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 5.3mm
Length 8.2mm
Height Seated (Max) 2mm
Technical
Turn Off Time 3.5 μs
High Side Driver NO
Current - Peak Output (Source, Sink) 1.2mA 1.2mA
Gate Type N-Channel, P-Channel MOSFET
Driven Configuration Low-Side
Supply Voltage1-Nom 12V
Channel Type Independent
Interface IC Type BUFFER OR INVERTER BASED MOSFET DRIVER
Rise / Fall Time (Typ) 3.5μs 3μs
Fall Time (Typ) 20 ns
Rise Time 30ns
Input Type Non-Inverting
Output Current 2.5mA
Nominal Supply Current 4.2mA
Power Supplies 5V
Operating Supply Voltage 5V
Number of Outputs 4
Pin Count 24
Base Part Number TPIC44L01
Terminal Pitch 0.65mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Subcategory MOSFET Drivers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Packaging Tube
Operating Temperature -40°C~150°C TJ
Physical
Weight 170.494032mg
Number of Pins 24
Package / Case 24-SSOP (0.209, 5.30mm Width)
Mounting Type Surface Mount
Mount Surface Mount
