TD310ID
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Tube TD310 Low-Side ACTIVE (Last Updated: 7months ago) gate driver 200ns 125C 600mA 0.8V 2V
PDF
/
Buying Options
Total Price: USD $2.46
Unit Price: USD $2.464
≥1 USD $2.464
≥10 USD $2.21056
≥100 USD $2.089824
≥500 USD $1.811128
≥1000 USD $1.718288
≥3000 USD $1.541795
Inventory: 1015
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 4mm
Length 10mm
Height 1.75mm
Technical
Ambient Temperature Range High 125°C
Turn Off Time 0.4 μs
Logic Voltage - VIL, VIH 0.8V 2V
High Side Driver YES
Max Junction Temperature (Tj) 150°C
Gate Type IGBT, N-Channel MOSFET
Driven Configuration Low-Side
Output Peak Current Limit-Nom 0.6A
Turn On Time 0.4 μs
Channel Type Independent
Interface IC Type BUFFER OR INVERTER BASED MOSFET DRIVER
Turn On Delay Time 400 ns
Input Type Inverting, Non-Inverting
Propagation Delay 200 ns
Max Supply Current 2mA
Output Current 600mA
Nominal Supply Current 1.5mA
Max Output Current 600mA
Output Voltage 5V
Number of Outputs 3
Pin Count 16
Base Part Number TD310
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 1.27mm
Supply Voltage 15V
Number of Functions 3
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4V~16V
Technology BICMOS
Subcategory MOSFET Drivers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
JESD-609 Code e4
Packaging Tube
Operating Temperature -40°C~150°C TJ
Physical
Number of Pins 16
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 12 Weeks
Alternative Model
