L9857-TR-LF
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Tape & Reel (TR) L9857 High-Side UNDER VOLTAGE gate driver 100ns 100ns -55C~150C TJ 500mA 500mA 300V
PDF
/
Buying Options
Total Price: USD $0.95
Unit Price: USD $0.954478
≥1 USD $0.954478
≥200 USD $0.370238
≥500 USD $0.357109
≥1000 USD $0.350544
Inventory: 1909
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3.9mm
Length 4.9mm
Technical
Output Current Flow Direction SOURCE
High Side Voltage - Max (Bootstrap) 300V
Built-in Protections UNDER VOLTAGE
Turn Off Time 0.2 μs
Current - Peak Output (Source, Sink) 500mA 500mA
Gate Type N-Channel MOSFET
Driven Configuration High-Side
Turn On Time 0.3 μs
Number of Drivers 1
Channel Type Single
Interface IC Type HALF BRIDGE BASED PERIPHERAL DRIVER
Rise / Fall Time (Typ) 100ns 100ns
Input Type Non-Inverting
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G8
Pin Count 8
Base Part Number L9857
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 15V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 10V~18V
Technology BCD
Subcategory Peripheral Drivers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
