L6743TR
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Tape & Reel (TR) L6743 Half-Bridge Non-Inverting gate driver 0C~125C TJ 2A - 1.15W 0.8V 2V
PDF
/
Buying Options
Total Price: USD $2.46
Unit Price: USD $2.456073
≥1 USD $2.456073
≥10 USD $2.317042
≥100 USD $2.18589
≥500 USD $2.062157
≥1000 USD $1.94544
Inventory: 1464
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 3.9mm
Length 4.9mm
Height Seated (Max) 1.75mm
Technical
High Side Voltage - Max (Bootstrap) 41V
Logic Voltage - VIL, VIH 0.8V 2V
High Side Driver YES
Current - Peak Output (Source, Sink) 2A -
Gate Type N-Channel MOSFET
Driven Configuration Half-Bridge
Number of Drivers 2
Channel Type Synchronous
Input Type Non-Inverting
Power Dissipation 1.15W
Nominal Supply Current 5mA
Max Output Current 3A
Pin Count 8
Base Part Number L6743
Time@Peak Reflow Temperature-Max (s) 30
Supply Voltage 12V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 5V~12V
Max Power Dissipation 1.15W
Subcategory MOSFET Drivers
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature 0°C~125°C TJ
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Alternative Model
