L6743BTR
RoHS
RoHS compliant
RoHS compliantPackage 8-VFDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Cut Tape (CT) L6743 Half-Bridge ACTIVE (Last Updated: 7months ago) gate driver 75ns 0C~125C TJ 2A - 0.8V 2V
PDF
/
Buying Options
Total Price: USD $4.98
Unit Price: USD $4.97705
≥1 USD $4.97705
≥10 USD $4.08405
≥100 USD $3.95675
≥500 USD $3.8285
≥1000 USD $3.7012
Inventory: 4636
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-VFDFN Exposed Pad
Number of Pins 8
Technical
Operating Temperature 0°C~125°C TJ
Packaging Cut Tape (CT)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 8
ECCN Code EAR99
Subcategory MOSFET Drivers
Voltage - Supply 5V~12V
Terminal Position DUAL
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 12V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number L6743
Pin Count 8
Qualification Status Not Qualified
Max Output Current 3A
Nominal Supply Current 5mA
Output Current 3A
Propagation Delay 75 ns
Input Type Non-Inverting
Channel Type Synchronous
Number of Drivers 2
Turn On Time 0.075 μs
Driven Configuration Half-Bridge
Gate Type N-Channel MOSFET
Current - Peak Output (Source, Sink) 2A -
High Side Driver YES
Logic Voltage - VIL, VIH 0.8V 2V
Turn Off Time 0.045 μs
High Side Voltage - Max (Bootstrap) 41V
Dimensions
Height Seated (Max) 1mm
Length 3mm
Width 3mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
