ISL6614IB-T
RoHS
/
Package 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Non-RoHS Compliant Obsolete N-Channel MOSFET Surface Mount IC Gate Driver 36V 1.25A 2A -40C~125C TJ 26ns 18ns
PDF
/
Inventory: 1109
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
High Side Voltage - Max (Bootstrap) 36V
Current - Peak Output (Source, Sink) 1.25A 2A
Gate Type N-Channel MOSFET
Driven Configuration Half-Bridge
Number of Drivers 4
Channel Type Synchronous
Rise / Fall Time (Typ) 26ns 18ns
Input Type Non-Inverting
Base Part Number ISL6614
Voltage - Supply 10.8V~13.2V
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TJ
Physical
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
