ISL6612ECB
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width) Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Non-RoHS Compliant Obsolete Matte Tin (Sn) - annealed e3 IC Gate Driver 36V 1.25A 2A 0C~125C TJ 26ns 18ns
PDF
/
Buying Options
Total Price: USD $1.77
Unit Price: USD $1.7688
≥1 USD $1.7688
Inventory: 2080
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
High Side Voltage - Max (Bootstrap) 36V
Current - Peak Output (Source, Sink) 1.25A 2A
Gate Type N-Channel MOSFET
Driven Configuration Half-Bridge
Number of Drivers 2
Channel Type Synchronous
Rise / Fall Time (Typ) 26ns 18ns
Input Type Non-Inverting
Pin Count 8
Base Part Number ISL6612
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Voltage - Supply 10.8V~13.2V
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Packaging Tube
Operating Temperature 0°C~125°C TJ
Physical
Package / Case 8-SOIC (0.154, 3.90mm Width) Exposed Pad
Mounting Type Surface Mount
