HIP6601BECB
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width) Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
GULL WING Non-RoHS Compliant Obsolete Matte Tin (Sn) IC Gate Driver 4.89mm 15V 0C~125C TJ 20ns 20ns
PDF
/
Buying Options
Total Price: USD $0.84
Unit Price: USD $0.8448
≥1 USD $0.8448
Inventory: 1010
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 3.9mm
Length 4.89mm
Height Seated (Max) 1.68mm
Technical
High Side Voltage - Max (Bootstrap) 15V
High Side Driver YES
Gate Type N-Channel MOSFET
Driven Configuration Half-Bridge
Number of Drivers 2
Channel Type Synchronous
Rise / Fall Time (Typ) 20ns 20ns
Input Type Non-Inverting
JESD-30 Code R-PDSO-G8
Base Part Number HIP6601B
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 12V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 10.8V~13.2V
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
JESD-609 Code e3
Packaging Tube
Operating Temperature 0°C~125°C TJ
Physical
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width) Exposed Pad
Mounting Type Surface Mount
