EL7457CL
RoHS
/
Package 16-VQFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Tube EL7457 High-Side or Low-Side Non-Inverting gate driver 13.5ns 13ns -40C~85C TA 2A 2A 0.8V 2V
PDF
/
Buying Options
Total Price: USD $48.59
Unit Price: USD $48.58965
≥1 USD $48.58965
≥10 USD $39.86865
≥100 USD $38.6232
≥500 USD $37.3768
≥1000 USD $36.13135
Inventory: 1017
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 16-VQFN Exposed Pad
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Technology CMOS
Voltage - Supply 4.5V~18V
Terminal Position QUAD
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 4
Supply Voltage 5V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number EL7457
Pin Count 16
JESD-30 Code S-PQCC-N16
Input Type Non-Inverting
Rise / Fall Time (Typ) 13.5ns 13ns
Interface IC Type BUFFER OR INVERTER BASED MOSFET DRIVER
Channel Type Independent
Number of Drivers 4
Negative Supply Voltage-Nom -5V
Driven Configuration High-Side or Low-Side
Gate Type N-Channel, P-Channel MOSFET
Current - Peak Output (Source, Sink) 2A 2A
High Side Driver YES
Logic Voltage - VIL, VIH 0.8V 2V
Dimensions
Height Seated (Max) 1.03mm
Compliance
RoHS Status Non-RoHS Compliant
