NCV5701BDR2G
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
ROHS3Compliant Active Tin (Sn) e3 IC Gate Driver 0.75V 4.3V 20mA 15mA -40C~125C TA 9.2ns 7.9ns
PDF
/
Inventory: 7090
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Technical
Operating Temperature -40°C~125°C TA
Packaging Tape & Reel (TR)
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1
Terminal Finish Tin (Sn)
Voltage - Supply 20V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Input Type Inverting
Rise / Fall Time (Typ) 9.2ns 7.9ns
Channel Type Single
Number of Drivers 1
Driven Configuration High-Side or Low-Side
Gate Type IGBT
Current - Peak Output (Source, Sink) 20mA 15mA
Logic Voltage - VIL, VIH 0.75V 4.3V
Compliance
RoHS Status ROHS3 Compliant
