NCP81074BDR2G
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Cut Tape (CT) Low-Side 2015 ACTIVE (Last Updated: 2days ago) gate driver 4ns 140C 10A 10A 20.3V
PDF
/
Buying Options
Total Price: USD $1.36
Unit Price: USD $1.3552
≥1 USD $1.3552
≥10 USD $1.21792
≥100 USD $1.14928
≥500 USD $0.919336
≥1000 USD $0.804461
≥3000 USD $0.781475
Inventory: 2160
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 3.9mm
Length 4.9mm
Height 1.75mm
Technical
Turn Off Time 0.027 μs
High Side Driver NO
Max Junction Temperature (Tj) 140°C
Current - Peak Output (Source, Sink) 10A 10A
Gate Type N-Channel MOSFET
Driven Configuration Low-Side
Output Peak Current Limit-Nom 10A
Turn On Time 0.027 μs
Number of Drivers 1
Channel Type Single
Interface IC Type BUFFER OR INVERTER BASED MOSFET DRIVER
Rise / Fall Time (Typ) 4ns 4ns
Fall Time (Typ) 4 ns
Rise Time 4ns
Input Type Inverting, Non-Inverting
Propagation Delay 15 ns
Output Current 600mA
Nominal Supply Current 1.2mA
Max Output Current 10A
Output Voltage 20.3V
Supply Voltage 12V
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~20V
Terminal Finish Tin (Sn)
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2015
Packaging Cut Tape (CT)
Operating Temperature -40°C~150°C TJ
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 14 Weeks
Alternative Model
