FAN7361M
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
RoHS Compliant Obsolete IGBT N-Channel MOSFET Surface Mount IC Gate Driver 5mm 1V 3.6V 625mW 250mA 500mA
PDF
/
Buying Options
Total Price: USD $2.77
Unit Price: USD $2.76545
≥1 USD $2.76545
≥10 USD $2.26955
≥100 USD $2.1983
≥500 USD $2.12705
≥1000 USD $2.05675
Inventory: 3007
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 4mm
Length 5mm
Height 1.5mm
Technical
High Side Voltage - Max (Bootstrap) 600V
Logic Voltage - VIL, VIH 1V 3.6V
Current - Peak Output (Source, Sink) 250mA 500mA
Gate Type IGBT, N-Channel MOSFET
Driven Configuration High-Side
Number of Drivers 1
Channel Type Single
Interface IC Type BUFFER OR INVERTER BASED IGBT/MOSFET DRIVER
Rise / Fall Time (Typ) 70ns 30ns
Fall Time (Typ) 100 ns
Rise Time 160ns
Turn On Delay Time 200 ns
Input Type Non-Inverting
Propagation Delay 200 ns
Power Dissipation 625mW
Nominal Supply Current 550μA
Max Output Current 500mA
Base Part Number FAN7361
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Voltage - Supply 10V~20V
Max Power Dissipation 625mW
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Packaging Tube
Operating Temperature -40°C~150°C TJ
Physical
Weight 230.4mg
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
