FAN7083M-GF085
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Tube FAN7083 High-Side 2005 gate driver 400ns -40C~150C TJ 200mA 400mA 625mW
PDF
/
Buying Options
Total Price: USD $19.4
Unit Price: USD $19.4009
≥1 USD $19.4009
≥10 USD $15.9182
≥100 USD $15.42135
≥500 USD $14.92355
≥1000 USD $14.42575
Inventory: 2099
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Weight 230.4mg
Technical
Operating Temperature -40°C~150°C TJ
Packaging Tube
Published 2005
Series Automotive, AEC-Q100
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Subcategory MOSFET Drivers
Max Power Dissipation 625mW
Voltage - Supply 10V~20V
Terminal Position DUAL
Terminal Form GULL WING
Supply Voltage 15V
Frequency 200kHz
Base Part Number FAN7083
Qualification Status Not Qualified
Max Output Current 400mA
Power Dissipation 625mW
Propagation Delay 250 ns
Input Type Non-Inverting
Rise Time 400ns
Fall Time (Typ) 200 ns
Rise / Fall Time (Typ) 200ns 25ns
Channel Type Single
Number of Drivers 1
Driven Configuration High-Side
Gate Type IGBT, N-Channel MOSFET
Current - Peak Output (Source, Sink) 200mA 400mA
High Side Voltage - Max (Bootstrap) 600V
Compliance
RoHS Status ROHS3 Compliant
Alternative Model
