FAN3180TSX

ON Semiconductor
RoHS
RoHS RoHS compliant
Package SC-74A, SOT-753
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description Tape & Reel (TR) FAN3180 Low-Side 2008 gate driver 19ns -40C~125C TJ 2.5A 2.8A 0.8V 2V
PDF
/
Buying Options
Total Price: USD $1.24
Unit Price: USD $1.2408
≥1 USD $1.2408
≥10 USD $1.10792
≥100 USD $1.051776
≥500 USD $0.807576
≥1000 USD $0.713645
≥3000 USD $0.676086
Inventory: 6742
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant
Radiation Hardening No

Dimensions

Width 1.7mm
Length 3mm
Height 1.3mm

Technical

Logic Voltage - VIL, VIH 0.8V 2V
Current - Peak Output (Source, Sink) 2.5A 2.8A
Gate Type N-Channel MOSFET
Driven Configuration Low-Side
Number of Drivers 1
Channel Type Single
Interface IC Type BUFFER OR INVERTER BASED MOSFET DRIVER
Rise / Fall Time (Typ) 19ns 13ns
Turn-Off Delay Time 35 ns
Fall Time (Typ) 13 ns
Rise Time 19ns
Max Input Voltage 18V
Min Input Voltage 4.5V
Turn On Delay Time 36 ns
Input Type Non-Inverting
Max Supply Current 200μA
Output Current 2.5A
Operating Supply Current 12.5mA
Max Output Current 2.8A
Output Type Fixed
Output Voltage 3.3V
Base Part Number FAN3180
Supply Voltage 12V
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 5V~18V
Subcategory MOSFET Drivers
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2008
Packaging Tape & Reel (TR)
Operating Temperature -40°C~125°C TJ

Physical

Weight 30mg
Number of Pins 5
Package / Case SC-74A, SOT-753
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 15 Weeks
