FAN3122TMPX
RoHS
RoHS compliant
RoHS compliantPackage 8-WDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Tape & Reel (TR) FAN3122 Low-Side 2014 gate driver 23ns -55C~150C TJ 10.6A 11.4A 396mW
PDF
/
Buying Options
Total Price: USD $1.7
Unit Price: USD $1.6984
≥1 USD $1.6984
≥10 USD $1.52856
≥100 USD $1.442144
≥500 USD $1.153856
≥1000 USD $1.009606
≥3000 USD $0.98076
Inventory: 7677
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 3mm
Length 3mm
Height 750μm
Technical
Built-in Protections UNDER VOLTAGE
Logic Voltage - VIL, VIH 0.8V 2V
Current - Peak Output (Source, Sink) 10.6A 11.4A
Gate Type N-Channel MOSFET
Driven Configuration Low-Side
Number of Drivers 1
Channel Type Single
Interface IC Type BUFFER OR INVERTER BASED PERIPHERAL DRIVER
Rise / Fall Time (Typ) 23ns, 19ns
Fall Time (Typ) 19 ns
Rise Time 23 ns
Turn On Delay Time 35 ns
Input Type Non-Inverting
Propagation Delay 35 ns
Max Supply Current 900μA
Output Current 9.7A
Operating Supply Current 650μA
Max Output Current 11.4A
Qualification Status Not Qualified
Base Part Number FAN3122
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.65mm
Supply Voltage 12V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form NO LEAD
Terminal Position DUAL
Voltage - Supply 4.5V~18V
Max Power Dissipation 396mW
Subcategory MOSFET Drivers
Terminal Finish Nickel/Palladium/Gold/Silver (Ni/Pd/Au/Ag)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Published 2014
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Weight 129mg
Number of Pins 8
Package / Case 8-WDFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
