TC4452VMF
RoHS
RoHS compliant
RoHS compliantPackage 8-VDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Tube TC4452 Low-Side 2006 gate driver 40ns -40C~150C TJ 13A 13A 0.8V 2.4V
PDF
/
Buying Options
Total Price: USD $2.6
Unit Price: USD $2.6048
≥1 USD $2.6048
≥10 USD $2.1648
≥100 USD $1.9712
Inventory: 2099
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-VDFN Exposed Pad
Number of Pins 8
Technical
Operating Temperature -40°C~150°C TJ
Packaging Tube
Published 2006
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory MOSFET Drivers
Voltage - Supply 4.5V~18V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number TC4452
Pin Count 8
Max Output Current 13A
Nominal Supply Current 200μA
Output Current 12A
Max Supply Current 200μA
Propagation Delay 52 ns
Input Type Non-Inverting
Turn On Delay Time 52 ns
Rise Time 40ns
Fall Time (Typ) 40 ns
Rise / Fall Time (Typ) 30ns 32ns
Interface IC Type BUFFER OR INVERTER BASED MOSFET DRIVER
Channel Type Single
Number of Drivers 1
Output Peak Current Limit-Nom 13A
Driven Configuration Low-Side
Gate Type IGBT, N-Channel, P-Channel MOSFET
Current - Peak Output (Source, Sink) 13A 13A
High Side Driver NO
Logic Voltage - VIL, VIH 0.8V 2.4V
