TC4427VMF
RoHS
RoHS compliant
RoHS compliantPackage 8-VDFN Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Tube TC4427 Low-Side 2004 gate driver 30ns -40C~150C TJ 1.5A 1.5A 0.8V 2.4V
PDF
/
Buying Options
Total Price: USD $0.68
Unit Price: USD $0.680082
≥1 USD $0.680082
≥10 USD $0.560608
≥30 USD $0.501528
≥100 USD $0.442447
≥500 USD $0.408312
≥1000 USD $0.389931
Inventory: 8965
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 5mm
Length 6mm
Height Seated (Max) 0.95mm
Technical
Turn Off Time 0.06 μs
Logic Voltage - VIL, VIH 0.8V 2.4V
High Side Driver YES
Current - Peak Output (Source, Sink) 1.5A 1.5A
Gate Type N-Channel, P-Channel MOSFET
Driven Configuration Low-Side
Output Peak Current Limit-Nom 1.5A
Turn On Time 0.04 μs
Number of Drivers 2
Channel Type Independent
Interface IC Type BUFFER OR INVERTER BASED MOSFET DRIVER
Rise / Fall Time (Typ) 19ns 19ns
Fall Time (Typ) 30 ns
Rise Time 30ns
Turn On Delay Time 50 ns
Input Type Non-Inverting
Propagation Delay 50 ns
Max Supply Current 4.5mA
Nominal Supply Current 4.5mA
Max Output Current 1.5A
Pin Count 8
Base Part Number TC4427
Time@Peak Reflow Temperature-Max (s) 40
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 4.5V~18V
Technology CMOS
Subcategory MOSFET Drivers
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2004
Packaging Tube
Operating Temperature -40°C~150°C TJ
Physical
Number of Pins 8
Package / Case 8-VDFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
Alternative Model
