TC4421ESM
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Tube TC4421 Low-Side 2004 gate driver 75ns -40C~150C TJ 9A 9A 750mW
PDF
/
Buying Options
Total Price: USD $3.94
Unit Price: USD $3.9424
≥1 USD $3.9424
≥10 USD $3.2912
≥100 USD $2.9832
Inventory: 152
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.209, 5.30mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~150°C TJ
Packaging Tube
Published 2004
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory MOSFET Drivers
Max Power Dissipation 750mW
Technology CMOS
Voltage - Supply 4.5V~18V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number TC4421
Pin Count 8
Max Output Current 9A
Nominal Supply Current 1.5mA
Power Dissipation 750mW
Max Supply Current 1.5mA
Propagation Delay 60 ns
Input Type Inverting
Turn On Delay Time 60 ns
Rise Time 75 ns
Fall Time (Typ) 75 ns
Rise / Fall Time (Typ) 60ns, 60ns
Interface IC Type BUFFER OR INVERTER BASED MOSFET DRIVER
Channel Type Single
Number of Drivers 1
Input Bias Current 10μA
Output Peak Current Limit-Nom 9A
Driven Configuration Low-Side
Gate Type IGBT, N-Channel, P-Channel MOSFET
Current - Peak Output (Source, Sink) 9A 9A
High Side Driver YES
Logic Voltage - VIL, VIH 0.8V 2.4V
Dimensions
Height 1.98mm
Length 5.26mm
Width 5.25mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
