TC4404EOA
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Tube TC4404 Low-Side 2006 gate driver 30ns -40C~85C TA 1.5A 1.5A 470mW
PDF
/
Inventory: 1
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 17 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 2006
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory MOSFET Drivers
Max Power Dissipation 470mW
Technology CMOS
Voltage - Supply 4.5V~18V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Turn Off Time 0.06 μs
Logic Voltage - VIL, VIH 0.8V 2.4V
High Side Driver YES
Current - Peak Output (Source, Sink) 1.5A 1.5A
Gate Type IGBT, N-Channel, P-Channel MOSFET
Driven Configuration Low-Side
Output Peak Current Limit-Nom 1.5A
Turn On Time 0.04 μs
Number of Drivers 2
Channel Type Independent
Interface IC Type BUFFER OR INVERTER BASED MOSFET DRIVER
Rise / Fall Time (Typ) 40ns, 40ns (Max)
Fall Time (Typ) 30 ns
Rise Time 30 ns
Turn On Delay Time 50 ns
Input Type Inverting
Propagation Delay 50 ns
Max Supply Current 4.5mA
Output Current 1.5A
Power Dissipation 470mW
Nominal Supply Current 4.5mA
Operating Supply Voltage 15V
Max Output Current 1.5A
Pin Count 8
Base Part Number TC4404
Time@Peak Reflow Temperature-Max (s) 40
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 3.91mm
Length 4.9mm
Height 1.42mm
