Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description Tube MIC5021 High-Side 2005 gate driver 500ns 85C 6mA 0.8V 2V
PDF
/
Buying Options
Total Price: USD $3.08
Unit Price: USD $3.08
≥1 USD $3.08
≥10 USD $2.552
≥100 USD $2.3232
Inventory: 872
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Width 3.94mm
Length 4.93mm
Height 1.73mm

Technical

Ambient Temperature Range High 85°C
Logic Voltage - VIL, VIH 0.8V 2V
Max Junction Temperature (Tj) 85°C
Gate Type IGBT, N-Channel MOSFET
Driven Configuration High-Side
Number of Drivers 1
Channel Type Single
Max Frequency 150kHz
Rise / Fall Time (Typ) 400ns 400ns
Turn-Off Delay Time 800 ns
Fall Time (Typ) 500 ns
Rise Time 500ns
Turn On Delay Time 500 ns
Input Type Non-Inverting
Output Current 6mA
Nominal Supply Current 1.7mA
Min Supply Voltage 12V
Max Supply Voltage 36V
Number of Channels 1
Max Output Current 6mA
Output Voltage 50V
Number of Outputs 1
Base Part Number MIC5021
Frequency 150kHz
Voltage - Supply 12V~36V
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Published 2005
Packaging Tube
Operating Temperature -40°C~85°C TA

Physical

Manufacturer Package Identifier SOICN-8LD-PL-1
Supplier Device Package 8-SOIC
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount

Supply Chain

Factory Lead Time 16 Weeks
