MIC4423YM
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Tube MIC4423 Low-Side 2005 gate driver 23ns 150C 3A 3A 960mW
PDF
/
Buying Options
Total Price: USD $1.81
Unit Price: USD $1.8128
≥1 USD $1.8128
≥10 USD $1.5136
≥100 USD $1.3728
Inventory: 707
Minimum: 1
-
+
Technical Details
Physical
Number of Pins 8
Supplier Device Package 8-SOIC
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Technical
Operating Temperature -40°C~150°C TJ
Packaging Tube
Published 2005
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Max Power Dissipation 960mW
Voltage - Supply 4.5V~18V
Base Part Number MIC4423
Number of Outputs 2
Output Voltage 25mV
Max Output Current 3A
Number of Channels 2
Max Supply Voltage 18V
Min Supply Voltage 4.5V
Nominal Supply Current 1.5mA
Output Current 3A
Propagation Delay 38 ns
Input Type Inverting
Turn On Delay Time 33 ns
Rise Time 23ns
Fall Time (Typ) 25 ns
Turn-Off Delay Time 33 ns
Rise / Fall Time (Typ) 28ns 32ns
Channel Type Independent
Number of Drivers 2
Driven Configuration Low-Side
Gate Type N-Channel, P-Channel MOSFET
Current - Peak Output (Source, Sink) 3A 3A
Max Junction Temperature (Tj) 150°C
Logic Voltage - VIL, VIH 0.8V 2.4V
Supply Chain
Factory Lead Time 7 Weeks
Dimensions
Height 1.73mm
Length 4.93mm
Width 3.94mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
