MIC4223YMME
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width) Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Tube MIC4223 Low-Side 2009 gate driver 15ns 125C 4A 4A 0.8V 2.4V
PDF
/
Buying Options
Total Price: USD $1.26
Unit Price: USD $1.2584
≥1 USD $1.2584
Inventory: 421
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Width 3mm
Length 3mm
Height 900μm
Technical
Logic Voltage - VIL, VIH 0.8V 2.4V
Current - Peak Output (Source, Sink) 4A 4A
Gate Type N-Channel MOSFET
Driven Configuration Low-Side
Number of Drivers 2
Channel Type Independent
Rise / Fall Time (Typ) 15ns 15ns
Fall Time (Typ) 15 ns
Rise Time 15ns
Turn On Delay Time 45 ns
Input Type Inverting
Propagation Delay 45 ns
Output Current 4A
Nominal Supply Current 1.7mA
Min Supply Voltage 4.5V
Max Supply Voltage 18V
Max Output Current 4A
Number of Outputs 2
Base Part Number MIC4223
Voltage - Supply 4.5V~18V
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Published 2009
Packaging Tube
Operating Temperature -40°C~125°C TJ
Physical
Supplier Device Package 8-MSOP-EP
Number of Pins 8
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width) Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
Alternative Model
