MCP14A1202-E/MS
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Tube Low-Side Non-Inverting BUFFER OR INVERTER BASED MOSFET DRIVER gate driver 25ns 25ns -40C~125C TA 12A 12A 0.8V 2V
PDF
/
Buying Options
Total Price: USD $0.39
Unit Price: USD $0.39387
≥1 USD $0.39387
≥200 USD $0.152428
≥500 USD $0.147071
≥1000 USD $0.144419
Inventory: 1372
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3mm
Length 3mm
Technical
Turn Off Time 0.037 μs
Logic Voltage - VIL, VIH 0.8V 2V
High Side Driver NO
Current - Peak Output (Source, Sink) 12A 12A
Gate Type IGBT, N-Channel, P-Channel MOSFET
Driven Configuration Low-Side
Output Peak Current Limit-Nom 12A
Turn On Time 0.037 μs
Number of Drivers 1
Channel Type Single
Interface IC Type BUFFER OR INVERTER BASED MOSFET DRIVER
Rise / Fall Time (Typ) 25ns 25ns
Input Type Non-Inverting
Supply Current-Max 0.6mA
JESD-30 Code S-PDSO-G8
Terminal Pitch 0.65mm
Number of Functions 2
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~18V
Number of Terminations 8
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Active
Packaging Tube
Operating Temperature -40°C~125°C TA
Physical
Surface Mount YES
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 7 Weeks
