MAX8811EEE+
RoHS
RoHS compliant
RoHS compliantPackage 16-SSOP (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Tube MAX8811 Half-Bridge 2007 gate driver 14ns 9ns -40C~150C TJ 6A 6A 666.7mW
PDF
/
Buying Options
Total Price: USD $7.77
Unit Price: USD $7.768429
≥1 USD $7.768429
≥200 USD $3.099757
≥500 USD $2.996038
≥1000 USD $2.944835
Inventory: 1353
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 16-SSOP (0.154, 3.90mm Width)
Number of Pins 16
Technical
Operating Temperature -40°C~150°C TJ
Packaging Tube
Published 2007
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory MOSFET Drivers
Max Power Dissipation 666.7mW
Technology BICMOS
Voltage - Supply 4.5V~7V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 6.5V
Terminal Pitch 0.635mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number MAX8811
Pin Count 16
Qualification Status Not Qualified
Max Output Current 30A
Power Supplies 6.5V
Max Supply Current 1.5mA
Input Type Non-Inverting
Rise / Fall Time (Typ) 14ns 9ns
Interface IC Type BUFFER OR INVERTER BASED MOSFET DRIVER
Channel Type Synchronous
Number of Drivers 4
Driven Configuration Half-Bridge
Gate Type N-Channel MOSFET
Current - Peak Output (Source, Sink) 6A 6A
High Side Driver NO
Logic Voltage - VIL, VIH 0.8V 2.6V
High Side Voltage - Max (Bootstrap) 30V
Dimensions
Height Seated (Max) 1.75mm
Width 3.9mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
