MAX620CWN
RoHS
/
Package 18-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
GULL WING Non-RoHS Compliant Obsolete Tin/Lead (Sn85Pb15) IC Gate Driver 11.55mm 0.8V 2.4V 762mW 25mA
PDF
/
Buying Options
Total Price: USD $68.65
Unit Price: USD $68.6546
≥1 USD $68.6546
≥10 USD $66.5095
≥100 USD $64.3644
≥500 USD $62.21835
≥1000 USD $55.7821
Inventory: 2290
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Dimensions
Width 7.5mm
Length 11.55mm
Height Seated (Max) 2.65mm
Technical
Logic Voltage - VIL, VIH 0.8V 2.4V
High Side Driver YES
Gate Type N-Channel MOSFET
Driven Configuration High-Side
Output Peak Current Limit-Nom 0.025A
Number of Drivers 4
Channel Type Independent
Interface IC Type BUFFER OR INVERTER BASED MOSFET DRIVER
Rise / Fall Time (Typ) 1.7μs 2.5μs
Fall Time (Typ) 2.5 μs
Rise Time 1.7μs
Input Type Non-Inverting
Max Supply Current 500μA
Nominal Supply Current 500μA
Power Supplies 5V
Max Output Current 25mA
Pin Count 18
Base Part Number MAX620
Terminal Pitch 1.27mm
Supply Voltage 5V
Number of Functions 4
Peak Reflow Temperature (Cel) 245
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~16.5V
Technology TTL
Max Power Dissipation 762mW
Subcategory MOSFET Drivers
Terminal Finish Tin/Lead (Sn85Pb15)
ECCN Code EAR99
Number of Terminations 18
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Published 1996
Packaging Tube
Operating Temperature 0°C~70°C TA
Physical
Number of Pins 18
Package / Case 18-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
