MAX15012DASA+T
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width) Exposed Pad
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Tape & Reel (TR) MAX15012 Half-Bridge 2008 gate driver 7ns -40C~150C TJ 2A 2A 470.6mW
PDF
/
Inventory: 1147
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width) Exposed Pad
Number of Pins 8
Technical
Operating Temperature -40°C~150°C TJ
Packaging Tape & Reel (TR)
Published 2008
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Max Power Dissipation 470.6mW
Voltage - Supply 8V~12.6V
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number MAX15012
Max Output Current 2A
Nominal Supply Current 140μA
Output Current 2A
Max Supply Current 3mA
Input Type Inverting, Non-Inverting
Turn On Delay Time 30 ns
Rise Time 7ns
Fall Time (Typ) 7 ns
Turn-Off Delay Time 30 ns
Rise / Fall Time (Typ) 65ns 65ns
Channel Type Independent
Number of Drivers 2
Driven Configuration Half-Bridge
Gate Type N-Channel MOSFET
Current - Peak Output (Source, Sink) 2A 2A
High Side Voltage - Max (Bootstrap) 175V
Compliance
RoHS Status ROHS3 Compliant
