ICL7667EPA
RoHS
/
Package 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Non-RoHS Compliant Obsolete Tin/Lead (Sn85Pb15) R-PDIP-T8 IC Gate Driver 9.375mm 0.8V 2V 0C~150C TJ 20ns 20ns
PDF
/
Buying Options
Total Price: USD $4.75
Unit Price: USD $4.752978
≥1 USD $4.752978
≥10 USD $4.48394
≥100 USD $4.230139
≥500 USD $3.990696
≥1000 USD $3.764797
Inventory: 1177
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Length 9.375mm
Technical
Turn Off Time 0.06 μs
Logic Voltage - VIL, VIH 0.8V 2V
High Side Driver YES
Gate Type N-Channel MOSFET
Driven Configuration Half-Bridge
Turn On Time 0.04 μs
Number of Drivers 2
Channel Type Independent
Interface IC Type BUFFER OR INVERTER BASED MOSFET DRIVER
Rise / Fall Time (Typ) 20ns 20ns
Input Type Inverting
Power Supplies 4.5/15V
Qualification Status Not Qualified
JESD-30 Code R-PDIP-T8
Pin Count 8
Base Part Number ICL7667
Time@Peak Reflow Temperature-Max (s) 20
Reach Compliance Code not_compliant
Supply Voltage 15V
Number of Functions 2
Peak Reflow Temperature (Cel) 240
Terminal Position DUAL
Voltage - Supply 4.5V~17V
Technology CMOS
Subcategory MOSFET Drivers
Terminal Finish Tin/Lead (Sn85Pb15)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Published 1995
Packaging Tube
Operating Temperature 0°C~150°C TJ
Physical
Surface Mount NO
Package / Case 8-DIP (0.300, 7.62mm)
Mounting Type Through Hole
