IXDI414YI
RoHS
/
Package TO-263-6, D2Pak (5 Leads + Tab), TO-263BA
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
GULL WING RoHS Compliant Obsolete R-PSSO-G5 IC Gate Driver 9.975mm 0.8V 3.5V 2W 14A 14A
PDF
/
Inventory: 1279
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-263-6, D2Pak (5 Leads + Tab), TO-263BA
Weight 1.59999g
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tube
Published 2004
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 5
ECCN Code EAR99
Max Power Dissipation 2W
Technology MOS
Voltage - Supply 4.5V~35V
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 18V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number IXD*414
Pin Count 4
JESD-30 Code R-PSSO-G5
Qualification Status Not Qualified
Operating Supply Voltage 35V
Nominal Supply Current 3mA
Output Current 14A
Input Type Inverting
Rise Time 27ns
Fall Time (Typ) 25 ns
Rise / Fall Time (Typ) 22ns 20ns
Interface IC Type BUFFER OR INVERTER BASED PERIPHERAL DRIVER
Channel Type Single
Number of Drivers 1
Turn On Time 0.033 μs
Output Peak Current Limit-Nom 14A
Driven Configuration Low-Side
Gate Type IGBT, N-Channel, P-Channel MOSFET
Current - Peak Output (Source, Sink) 14A 14A
Logic Voltage - VIL, VIH 0.8V 3.5V
Turn Off Time 0.034 μs
Dimensions
Height Seated (Max) 4.8mm
Length 9.975mm
Compliance
RoHS Status RoHS Compliant
