ISL89161FRTAZ
RoHS
/
Package /
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
NO LEAD RoHS Compliant Active Matte Tin (Sn) - annealed IC Gate Driver 3mm 16V 33.3W 6A
PDF
/
Buying Options
Total Price: USD $3.11
Unit Price: USD $3.1064
≥1 USD $3.1064
Inventory: 866
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 3mm
Length 3mm
Technical
Turn Off Time 0.05 μs
High Side Driver YES
Output Peak Current Limit-Nom 6A
Turn On Time 0.05 μs
Number of Drivers 2
Interface IC Type AND GATE BASED MOSFET DRIVER
Turn-Off Delay Time 25 ns
Fall Time (Typ) 20 ns
Rise Time 20ns
Turn On Delay Time 25 ns
Current - Output 6A
Power Dissipation-Max 33.3W
Min Supply Voltage 4.5V
Max Supply Voltage 16V
Temperature Grade AUTOMOTIVE
Max Output Current 6A
Qualification Status Not Qualified
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 0.65mm
Supply Voltage 12V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form NO LEAD
Terminal Position DUAL
Subcategory MOSFET Drivers
Min Operating Temperature -40°C
Max Operating Temperature 125°C
Terminal Finish Matte Tin (Sn) - annealed
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3
Part Status Active
JESD-609 Code e3
Published 2010
Physical
Number of Pins 8
Mount Surface Mount
