ISL6207CB-T
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
GULL WING Non-RoHS Compliant Discontinued Tin/Lead (Sn/Pb) IC Gate Driver 4.9mm 5V 4A 85C
PDF
/
Buying Options
Total Price: USD $8.56
Unit Price: USD $8.56425
≥1 USD $8.56425
≥10 USD $7.02715
≥100 USD $6.8077
≥500 USD $6.5873
≥1000 USD $6.36785
Inventory: 19108
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Package / Case SOIC
Technical
Packaging Tape & Reel (TR)
Published 2001
JESD-609 Code e0
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Max Operating Temperature 85°C
Min Operating Temperature -10°C
Subcategory MOSFET Drivers
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Number of Functions 1
Supply Voltage 5V
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 8
JESD-30 Code R-PDSO-G8
Number of Outputs 2
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 5V
Temperature Grade OTHER
Supply Voltage-Min (Vsup) 4.5V
Interface IC Type HALF BRIDGE BASED MOSFET DRIVER
Turn On Time 0.03 μs
Output Peak Current Limit-Nom 4A
High Side Driver YES
Dimensions
Height Seated (Max) 1.75mm
Length 4.9mm
Width 3.9mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
