IRS21953STRPBF
RoHS
/
Package 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Tape & Reel (TR) IRS21953SPBF Half-Bridge Low-Side 1996 gate driver 70ns -55C~150C TJ 500mA 500mA 1W
PDF
/
Buying Options
Total Price: USD $4.15
Unit Price: USD $4.1477
≥1 USD $4.1477
≥10 USD $3.40385
≥100 USD $3.29745
≥500 USD $3.19105
≥1000 USD $3.08465
Inventory: 6368
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 3.9878mm
Length 9.9568mm
Height 1.4986mm
Technical
High Side Voltage - Max (Bootstrap) 600V
Built-in Protections TRANSIENT; UNDER VOLTAGE
Logic Voltage - VIL, VIH 0.6V 3.5V
Current - Peak Output (Source, Sink) 500mA 500mA
Gate Type N-Channel MOSFET
Driven Configuration Half-Bridge, Low-Side
Output Peak Current Limit-Nom 0.5A
Number of Drivers 3
Channel Type Independent
Interface IC Type BUFFER OR INVERTER BASED PERIPHERAL DRIVER
Rise / Fall Time (Typ) 25ns 25ns
Fall Time (Typ) 70 ns
Rise Time 70ns
Input Type Non-Inverting
Propagation Delay 380 ns
Output Current 500mA
Power Dissipation 1W
Power Supplies 15V
Max Output Current 500mA
Qualification Status Not Qualified
Base Part Number IRS21953SPBF
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 1.27mm
Supply Voltage 15V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 10V~20V
Technology CMOS
Max Power Dissipation 1W
Subcategory MOSFET Drivers
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
JESD-609 Code e3
Published 1996
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Number of Pins 16
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
