IRS21856STRPBF
RoHS
/
Package 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Tape & Reel (TR) IRS21856SPBF Half-Bridge 1996 gate driver 70ns -55C~150C TJ 500mA 500mA 1W
PDF
/
Buying Options
Total Price: USD $1.51
Unit Price: USD $1.51335
≥1 USD $1.51335
≥10 USD $1.2426
≥100 USD $1.20365
≥500 USD $1.1647
≥1000 USD $1.12575
Inventory: 15005
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Width 3.9878mm
Length 8.7376mm
Height 1.4986mm
Technical
High Side Voltage - Max (Bootstrap) 600V
Logic Voltage - VIL, VIH 0.8V 3.5V
Current - Peak Output (Source, Sink) 500mA 500mA
Gate Type IGBT, N-Channel MOSFET
Driven Configuration Half-Bridge
Number of Drivers 2
Channel Type Independent
Interface IC Type BUFFER OR INVERTER BASED PERIPHERAL DRIVER
Rise / Fall Time (Typ) 30ns 20ns
Turn-Off Delay Time 160 ns
Fall Time (Typ) 70 ns
Turn On Delay Time 150 ns
Input Type Non-Inverting
Output Current 500mA
Nominal Supply Current 120μA
Max Output Current 500mA
Base Part Number IRS21856SPBF
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Voltage - Supply 10V~20V
Max Power Dissipation 1W
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
Published 1996
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Number of Pins 14
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Alternative Model
