IR2235STRPBF
RoHS
RoHS compliant
RoHS compliantPackage 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Tape & Reel (TR) IR2235SPBF Half-Bridge 1996 gate driver 150ns 125C TJ 250mA 500mA 1.6W
PDF
/
Buying Options
Total Price: USD $12.04
Unit Price: USD $12.036667
≥1 USD $12.036667
≥200 USD $4.658169
≥500 USD $4.49537
≥1000 USD $4.41397
Inventory: 6332
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 28-SOIC (0.295, 7.50mm Width)
Number of Pins 28
Technical
Operating Temperature 125°C TJ
Packaging Tape & Reel (TR)
Published 1996
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 28
Resistance 100Ohm
Terminal Finish Matte Tin (Sn)
Max Power Dissipation 1.6W
Voltage - Supply 10V~20V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 3
Supply Voltage 15V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number IR2235SPBF
Number of Outputs 3
Output Voltage 15V
Max Output Current 500mA
Nominal Supply Current 4mA
Output Current 500mA
Input Type Inverting
Rise Time 150ns
Fall Time (Typ) 70 ns
Rise / Fall Time (Typ) 90ns 40ns
Channel Type 3-Phase
Number of Drivers 6
Turn On Time 1 μs
Output Peak Current Limit-Nom 0.5A
Driven Configuration Half-Bridge
Gate Type IGBT, N-Channel MOSFET
Current - Peak Output (Source, Sink) 250mA 500mA
High Side Driver YES
Logic Voltage - VIL, VIH 0.8V 2V
Turn Off Time 0.95 μs
High Side Voltage - Max (Bootstrap) 1200V
Dimensions
Height 2.3622mm
Length 18.0848mm
Width 7.5946mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
