IR21834SPBF
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Tube IR21834SPBF Half-Bridge 1996 gate driver 60ns -40C~150C TJ 1.9A 2.3A 1W
PDF
/
Buying Options
Total Price: USD $4
Unit Price: USD $3.9952
≥1 USD $3.9952
≥10 USD $3.59128
≥100 USD $3.395392
≥500 USD $2.942544
≥1000 USD $2.791642
≥3000 USD $2.504955
Inventory: 2037
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 26 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-SOIC (0.154, 3.90mm Width)
Number of Pins 14
Technical
Operating Temperature -40°C~150°C TJ
Packaging Tube
Published 1996
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 14
Termination SMD/SMT
ECCN Code EAR99
Terminal Finish Tin (Sn)
Subcategory MOSFET Drivers
Max Power Dissipation 1W
Technology CMOS
Voltage - Supply 10V~20V
Terminal Position DUAL
Terminal Form GULL WING
Number of Functions 1
Supply Voltage 15V
Base Part Number IR21834SPBF
Number of Outputs 2
Output Voltage 620V
Max Output Current 2.3A
Nominal Supply Current 1.6mA
Power Dissipation 1W
Output Current 1.9A
Max Supply Current 1.6mA
Propagation Delay 330 ns
Input Type Inverting, Non-Inverting
Turn On Delay Time 35 ns
Max Output Voltage 20V
Rise Time 60 ns
Fall Time (Typ) 35 ns
Turn-Off Delay Time 220 ns
Min Output Voltage 10V
Rise / Fall Time (Typ) 40ns, 20ns
Channel Type Independent
Output Peak Current Limit-Nom 2.3A
Driven Configuration Half-Bridge
Gate Type IGBT, N-Channel MOSFET
Current - Peak Output (Source, Sink) 1.9A 2.3A
High Side Driver YES
Logic Voltage - VIL, VIH 0.8V 2.7V
Turn Off Time 0.33 μs
High Side Voltage - Max (Bootstrap) 600V
Dimensions
Height 1.4986mm
Length 8.74mm
Width 3.99mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
