IR21814PBF
RoHS
RoHS compliant
RoHS compliantPackage 14-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Tube IR21814PBF Half-Bridge 1996 gate driver 60ns -40C~150C TJ 1.9A 2.3A 1.6W
PDF
/
Buying Options
Total Price: USD $1.93
Unit Price: USD $1.9272
≥1 USD $1.9272
Inventory: 1566
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 7.11mm
Length 20.1676mm
Height 4.9276mm
Technical
High Side Voltage - Max (Bootstrap) 600V
Turn Off Time 0.33 μs
Logic Voltage - VIL, VIH 0.8V 2.7V
High Side Driver YES
Current - Peak Output (Source, Sink) 1.9A 2.3A
Gate Type IGBT, N-Channel MOSFET
Driven Configuration Half-Bridge
Output Peak Current Limit-Nom 2.3A
Number of Drivers 2
Channel Type Independent
Rise / Fall Time (Typ) 40ns 20ns
Turn-Off Delay Time 330 ns
Fall Time (Typ) 35 ns
Rise Time 60ns
Turn On Delay Time 270 ns
Input Type Non-Inverting
Propagation Delay 330 ns
Output Current 1.9A
Power Dissipation 1.6W
Power Supplies 15V
Max Output Current 2.3A
Output Voltage 620V
Base Part Number IR21814PBF
Supply Voltage 15V
Number of Functions 1
Terminal Position DUAL
Voltage - Supply 10V~20V
Technology CMOS
Max Power Dissipation 1.6W
Subcategory MOSFET Drivers
ECCN Code EAR99
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Last Time Buy
Published 1996
Packaging Tube
Operating Temperature -40°C~150°C TJ
Physical
Number of Pins 14
Package / Case 14-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 18 Weeks
