IR2133STR
RoHS
/
Package 28-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
GULL WING Non-RoHS Compliant Obsolete Matte Tin (Sn) IC Gate Driver 17.9mm 0.8V 2.2V 250mA 500mA 125C TJ
PDF
/
Buying Options
Total Price: USD $1.18
Unit Price: USD $1.182629
≥1 USD $1.182629
≥10 USD $1.115689
≥100 USD $1.052537
≥500 USD $0.992954
≥1000 USD $0.936754
Inventory: 7048
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 7.5mm
Length 17.9mm
Technical
High Side Voltage - Max (Bootstrap) 600V
Turn Off Time 0.95 μs
Logic Voltage - VIL, VIH 0.8V 2.2V
High Side Driver YES
Current - Peak Output (Source, Sink) 250mA 500mA
Gate Type IGBT, N-Channel MOSFET
Driven Configuration Half-Bridge
Output Peak Current Limit-Nom 0.5A
Turn On Time 1 μs
Number of Drivers 6
Channel Type 3-Phase
Rise / Fall Time (Typ) 90ns 40ns
Input Type Inverting
Power Supplies 15V
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G28
Base Part Number IR2133S
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Terminal Pitch 1.27mm
Supply Voltage 15V
Number of Functions 3
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 10V~20V
Technology BICMOS
Subcategory MOSFET Drivers
HTS Code 8542.39.00.01
Additional Feature FLOATING LOAD DRIVER; UNDER VOLTAGE LOCKOUT CIRCUIT
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 28
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e3
Published 2005
Packaging Tape & Reel (TR)
Operating Temperature 125°C TJ
Physical
Surface Mount YES
Package / Case 28-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
