IR2114SSPBF
RoHS
RoHS compliant
RoHS compliantPackage 24-SSOP (0.209, 5.30mm Width)
Category Integrated Circuits (ICs) / PMIC - Gate Drivers
Description
Tube IR2114SSPBF Half-Bridge 1996 gate driver 24ns 125C 2A 3A 1.5W
PDF
/
Buying Options
Total Price: USD $5.02
Unit Price: USD $5.016
≥1 USD $5.016
≥10 USD $4.5276
≥100 USD $4.31728
≥500 USD $3.748721
≥1000 USD $3.707774
Inventory: 1669
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 24-SSOP (0.209, 5.30mm Width)
Number of Pins 24
Technical
Operating Temperature -40°C~150°C TJ
Packaging Tube
Published 1996
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 24
ECCN Code EAR99
Type Integrated Circuit (IC)
Resistance 60Ohm
Terminal Finish Matte Tin (Sn)
Subcategory MOSFET Drivers
Max Power Dissipation 1.5W
Technology CMOS
Voltage - Supply 11.5V~20V
Ambient Temperature Range High 125°C
High Side Voltage - Max (Bootstrap) 600V
Built-in Protections TRANSIENT; OVER CURRENT; UNDER VOLTAGE
Turn Off Time 0.66 μs
Logic Voltage - VIL, VIH 0.8V 2V
Max Junction Temperature (Tj) 150°C
Current - Peak Output (Source, Sink) 2A 3A
Gate Type IGBT
Driven Configuration Half-Bridge
Turn On Time 0.66 μs
Channel Type Independent
Rise / Fall Time (Typ) 24ns, 7ns
Turn-Off Delay Time 440 ns
Fall Time (Typ) 7 ns
Rise Time 24 ns
Turn On Delay Time 440 ns
Input Type Non-Inverting
Propagation Delay 440 ns
Max Supply Current 2.5mA
Output Current 1A
Power Dissipation 1.5W
Nominal Supply Current 2.5mA
Power Supplies 15V
Max Output Current 3A
Output Voltage 620V
Number of Outputs 2
Base Part Number IR2114SSPBF
Terminal Pitch 0.65mm
Supply Voltage 15V
Number of Functions 1
Terminal Form GULL WING
Terminal Position DUAL
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 5.3mm
Length 8.2mm
Height 2mm
